5.6.4 Configuring the CAN/LIN Interfaces
Calling up the Configuration Page on the Web Interface
Calling up the configuration page:
• Start the ES910.3-A web interface (see chapter
5.6.2 on page 60).
• Click Device configuration.
• Click Port Settings.
The page for configuring the CAN/LIN interfaces is
displayed.
Configuring the CAN Interfaces
For more details on the configurable parameters of the CAN interfaces, refer to
chapter 4.8 on page 30. The CAN interfaces can be configured independently of
one another.
To configure the CAN1 interface:
• Select “High Speed”.
The CAN1 interface is operated in the operating
mode “High-Speed”.
or
• Select “Low Speed / Fault Tolerant”.
The CAN1 interface is operated in the operating
mode “Low-Speed”.
• Click Save Config.
The configuration of the CAN1 interface is saved.
To configure the CAN2 interface:
• Select “High Speed”.
The CAN2 interface is operated in the operating
mode “High-Speed”.
or
• Select “Low Speed / Fault Tolerant”.
The CAN2 interface is operated in the operating
mode “Low-Speed”.
• Click Save Config.
The configuration of the CAN2 interface is saved.
Note
After changing a configuration on the web interface of ES910.3-A, the module
has to be restarted!
