ETAS ES910.3-A - Configuring the ECU Interface

ES910.3-A - User’s Guide 63
ETAS Getting Started
• Click on Port Settings.
The page for configuring the IO interface is dis-
played.
Configuring the IO Interface
To configure the IO interface
• Under the Port Micro I/O Interface, select the
"ES400 daisy chain" setting.
The IO interface is configured for operating with
daisy chain modules.
or
• Under the Port Micro I/O Interface, select the "Eth-
erCAT slave" setting.
• For EtherCAT mode, select the "EtherCAT
enhanced mode" setting.
The IO interface is configured for operating in the
EtherCAT mode.
• Click on Save Config.
The configuration of the IO interface is being saved.
5.6.6 Configuring the ECU Interface
Calling up the Configuration Page on the Web Interface
Calling up the configuration page:
• Start the ES910.3-A web interface (see chapter
5.6.2 on page 60).
• Click on Device Configuration.
• Click on Ethernet Configuration.
The page for configuring the internal switch (Ether-
net layer 2 software bridge) of ES910.3-A is dis-
played.
Note
After changing a configuration on the web interface of ES910.3-A, the module
has to be restarted!
