ES910.3-A - User’s Guide 81
ETAS Technical Data
7.7 Electrical Data
7.7.1 Power Supply
7.7.2 Simulation Controller
7.7.3 PC Interface (PC)
Operating voltage range 7 to 29 V DC
Operating voltage, typ. 12 V DC
Current consumption, operation 1,2 A, typ. (at 12 V)
1,7 A, max. (at 12 V)
Current consumption, standby < 25 mA
Current consumption, max. 5 A
Protection
1)
Protected against polarity inversion and
Load Dump protection
1)
: The module may be used only with central load dump protection.
Controller Freescale PowerPC PowerQUICC
TM
III
MPC8548, 800 MHz
Memory 512 MByte DDR2-RAM (400 MHz clock)
64 MByte Flash
128 kByte NVRAM (32 kByte address-
able)
Operating system OSEK Real-Time
Connection 10/100/1000 Mbit/s Ethernet,
Full Duplex
Protocol TCP/IP
IP address Dynamic via INTECRIO or INCA
Support of the ETAS synchronization
mechanism
SYNC IN functionality
To ensure successful initialization of the network card of your PC, refer to chap-
ter 7.6.1 on page 77.
