Configuring the LIN Interfaces
For more details on the configurable parameters of the LIN interfaces, refer to
chapter 4.9 on page 31. The LIN interfaces can be configured independently of
one another.
To configure the LIN1 interface:
• Select “Master resistor disconnected”.
The LIN1 interface is operated without the internal
termination resistor.
or
• Select “Master resistor connected”.
The LIN1 interface is operated with the internal ter-
mination resistor.
• Click Save Config.
The configuration of the LIN1 interface is saved.
To configure the LIN2 interface:
• Select “Master resistor disconnected”.
The LIN2 interface is operated without the internal
termination resistor.
or
• Select “Master resistor connected”.
The LIN2 interface is operated with the internal ter-
mination resistor.
• Click Save Config.
The configuration of the LIN2 interface is saved.
5.6.5 Configuring the IO Interface
For notes about the configurable parameters of the IO interface, see chapter
4.11 on page 34.
Calling up the Configuration Page on the Web Interface
Calling up the configuration page:
• Start the ES910.3-A web interface (see chapter
5.6.2 on page 60).
• Click on Device Configuration.
Note
After changing a configuration on the web interface of ES910.3-A, the module
has to be restarted!
Note
At the "IO" interface, it is possible to use either ETAS daisy chain modules or
the EtherCAT automation bus. The simultaneous use at an ES910.3-A module
is not possible.
