ES910.3-A - User’s Guide 99
ETAS Cables and Accessories
Connector Pin assignment of Cable at the CAN1/LIN1 or CAN2/LIN2 Interface
The DSUB socket plug combinations of the CBCFI100 cable are assigned the sig-
nals of the CAN1/LIN1 or CAN2/LIN2 interface of ES910.3-A as follows:
Lemo 
[Side A]
DSUB, 
Color: gray 
[Side B, Side C]
Pin Signal Pin Signal
1 LIN_UBATT
1-
2 CAN_LOW
2 CAN_LOW
3 CAN_GND
3 CAN_GND
4LIN
4-
5LIN_GND
5-
6 CAN_GND
6 CAN_GND
7 CAN_HIGH
7 CAN_HIGH
8 CAN_UBATT
8-
9-
DSUB, 
Color: black
[Side D, Side E]
Pin Signal
1-
2 Reserved, do
not use
3LIN_GND
4-
5-
6-
7LIN
8-
9 LIN_UBATT
