3025SW Master Control Switching & Channel Branding
Revision 1.0 Page 87
Fade Cut Transition
Selects a Fade-Cut
transition.
N/A N/A
Audio Follow Video
Transition
Selects the audio
mode.
N/A N/A
Audio Only
Transition
Selects the audio
mode.
N/A N/A
Audio Lag
Transition
Selects the audio
mode.
N/A N/A
Audio Lead
Transition
Selects the audio
mode.
N/A N/A
Fade to Black
Selects fade to
black/silence and held
in black/silence while
held active
N/A N/A
Bypass QMC
Selects bypass and
held in bypass while
held active
N/A N/A
Mix Lead Active
Not supported
Mix Lag Active
Not supported
Preset Source
Selects the source
defined by parameter
1 to the preset bus
Source number ZERO
based, i.e. for
PSTSRC 1 set this to
0.
N/A
Program Source
Selects the source
defined by parameter
1 to the program bus
Source number ZERO
based, i.e. for PGM
SRC 1 set this to 0.
N/A
Logo Selection
Not supported on SW
N/A
N/A
DVE Level
Selects the DVE ready
for the next transition
0: Primary DVE
1: Secondary DVE
N/A
DVE On-Air
Selects the DVE on-air
while held active
0: Primary DVE
1: Secondary DVE
N/A
Select DVE Move
Selects the next DVE
move as defined by
parameter 1
DVE Move. 1 for
move 1, 2 for move 2,
etc.
0: Primary DVE Move
1: Secondary DVE Move
Start DVE Move
Selects the DVE onto
the Program bus using
the move defined by
parameter 1
DVE Move. 1 for
move 1, 2 for move 2,
etc.
0: Primary DVE Move
1: Secondary DVE Move
DVE Background
Source
Selects the DVE
background as defined
by parameter 1
DVE Background. 0 for
source 1, 1 for source
2, etc.
N/A
Execute Current
DVE Move
Runs the currently
selected DVE on the
specified bus
1: Primary PGM
2: Primary PVW
3: Secondary PGM
4: Secondary PVW
N/A
Trigger Manual GPI
Not supported on SW.
