3025SW Master Control Switching & Channel Branding
Page 182 Revision 1.0
9.2.4. GPI TALLY
The corresponding EMCGPI will tally this button when the GPI is active. The EMC GPI Must be
configured to be “Panel GPI Tally”.
The corresponding DCP GPI will tally this button then the GPI is active.
9.3. UPGRADING THE 3025SW FIRMWARE
There are three ways to upgrade the firmware on the 3025SW, either using Overture Media Manager
software, ftp console or serial.
9.3.1. Overture Media Manager
1. Left Click on the 3025SW device that you want to upgrade and then select View Media.
2. When the media list has been retrieved from the 3025SW, left click File then select “Upgrade…”
3.
4. Navigate to the firmware required (.bin extension), confirm the filename and then select “Open”.
5. An upgrade dialogue box will be displayed that will confirm the firmware location, version and
build and creation date and time.
6. Confirm that the hardware status of the 3025SW is “Ready to Upgrade” and confirm if you want
t he unit to reboot automatically when the upload of the new firmware file is completed.
7. Click “Upgrade” to proceed with the upgrade or “Cancel” to return to the Overture Media
Manger main dialogue window.
8. The progress of the firmware upload can be monitored using the Transfer Queue status in the
Status Window dialogue at the bottom of the Media Manager main window.
9.3.2. FTP Console
1. Open an anonymous ftp connection to the 3025SW (e.g. ftp 192.168.9.100 –A).
2. Type “cd app”.
3. Type “hash”.
4. Type “put” and then drag the required firmware .bin file into the ftp console and press “Enter”.
5. The transfer of the firmware file to the app directory of the 3025SW will proceed.
6. Confirm that the transfer was completed successfully.
7. When completed the unit will need to be re-booted in order for the new firmware loading process
to be completed.
The recommended way to reboot the 3025SW is by using the webpage interface.
