3025SW Master Control Switching & Channel Branding
Revision 1.0 Page 53
Voiceover 5
Embedded: This configures the voiceover 5 bus to use de-embedded audio from a serial video
input. When this is configured the “De-embedder Source” drop-down menu becomes
available. Any of Key1, Fill1, Key2, Fill2, Key3, Fill3, Aux1, Aux2, Aux3, DVE1 and
DVE2 can be assigned to the voiceover 5 de-embedder. See Table 4-3 on page 49 for
details on how the input bus corresponds to the 3025SW-IO-BNC rearplate.
AES MADI: Not Supported on the 3025SW.
Voiceover 4
Embedded: This configures the voiceover 4 bus to use de-embedded audio from a serial video
input. When this is configured the “De-embedder Source” drop-down menu becomes
available. Any of Key1, Fill1, Key2, Fill2, Key3, Fill3, Aux1, Aux2, Aux3, DVE1 and
DVE2 can be assigned to the voiceover 4 de-embedder. See Table 4-3 on page 49 for
details on how the input bus corresponds to the 3025SW-IO-BNC rearplate.
Audio Clip: When in this configuration VO4 is used to playout an audio wav file that is stored either
in the internally (Compact Flash) or on the Network Attached Storage (NAS). The
3025EMC will support 8ch 48 kHz 16 bit stereo OR 8ch 48 kHz 8 bit mono audio wav
files. Only these two types are supported. VO4 will go on-air (wav is faded in) or preset
(wav is cue’s). Only one wav file can be on-air at any time.
AES MADI: Not Supported on the 3025SW.
4.5.2. Metadata Router/Metadata Presets
Please note: Metadata Control/Metadata Presets are currently NOT supported on
the 3025SW platform.
4.5.3. Operational Options
4.5.3.1. Change Input Parameters on Source
When the preset or program bus is changed from source to source the 3025SW can optionally change
the audio gain and shuffling of the input bus to the configuration determined by that source. This option
enables this function to be active, if the option is not checked then the audio parameters do not change
when source selections are made to the preset or program bus. When this mode is not active the gain
and shuffle settings are global for that bus regardless of the currently selected source.
4.5.3.2. Assign Default on No Source Parameter
If the above option is enabled then the audio settings can optionally be assigned to the default values if
a particular source has no audio parameters associated with it (see source dialog for more details).
