Delete: Delete a source from the list.
To start, the user must select Add button to add the number of sources that will be available to the
3025SW. In the dialog box, enter the number of sources.
Note: The maximum number of sources that a 3025SW can use is 15 (including
internally generated test pattern). This depends on the configuration of the device.
The number of sources that should be added depends on the configuration. See the table below to
determine how may sources should be added to the source table.
Size of Source Table (includes test pattern)
No Keyers and No Emergency
Keyer 1, Keyer 2 & Emergency
Table 5-1: 3025SW Source Table by Configuration
5.1. CONFIGURING CURRENT SOURCE
The user now must select a source from the list that has been populated with the number of sources
available to 3025SW.
Router Index: THIS DOES NOT APPLY TO THE 3025SW AND SHOULD NOT BE CHANGED
FROM THE DEFAULT VALUES.
Identification: This the name of the source and how it will appear on LCD buttons of the control
panels. By selecting the Auto-assign box, the name entered will be copied
automatically to the LCD legend.
5.1.1. Audio Parameters
These are audio parameters the user may want to define on a per source basis.
Video Only: Check this option for sources that do not have any discrete audio associated with
them; this prevents the 3025SW requesting audio routes of the upstream router when
they are not required. When this option is checked all other audio options are disabled.
Shuffle: This drop-down combo box selects any audio shuffling stores configure in section 4.7
applied to the 3025SW when this source is selected to the preset or program bus. If no
change is required when this source is selected set this to the first selection
"Unchanged".
Format: This drop-down combo box selects the audio format type for the 3025SW when this
source is selected to the preset or program bus. If no change is required when this
source is selected then set this to the first selection "Unchanged".
