3025SW Master Control Switching & Channel Branding
Page 44 Revision 1.0
The Video Transition Offset can be configured in a range from -4 to +4. The setting is in
fields for interlaced video standards and frames for progressive video standards.
NOTE: When the Mini Master Mode is enabled the user should exit the channel
configuration for the setting to take effect.
4.4. VIDEO CONFIGURATION
Figure 4-11: Video Tab
4.4.1. Video Standard
This parameter enables you to select a desired video standard. This sets the video standard of the
3025SW channel. This section allows for the configuration of the reference signal type of “HD Tri-level
Sync” or “Bi-level Sync” option.
