3025SW Master Control Switching & Channel Branding
Page 136 Revision 1.0
7.2.2.1. Start Frame
This configures the start position of the DVE move. These settings are based on the video standard
configured on the 3025SW. The DVE move editor has a box on the right side of the Start Frame
section to allow users to see what they are doing with editing the start frame parameters.
Position: This is the X and Y co-ordinates of the starting position of the DVE. The (0, 0) co-
ordinate represents the top left corner of the DVE move after the video has been
cropped.
Horizontal Size: The horizontal size of the start frame can be defined by editing a specific number of
pixels or a percentage of the full horizontal pixel length.
Vertical Size: The vertical size of the start frame can be defined by editing a specific number of lines or a
percentage of the total number of vertical lines.
Full Screen: This checked if you want the starting frame to be full screen.
Start from Current Position: This checked if you want the starting frame to from the current position
of the video. This move could be a continuation of another DVE move
Crop Frame: This allows the user to crop a portion of the start frame.
7.2.2.2. End Frame
This configures the end position of the DVE move. These settings are based on the video standard
configured on the 3025SW. The DVE move editor has box on the right side of the End Frame section
to allow users to see what they are doing with editing the end frame parameters.
Position: This is the X and Y co-ordinates of the end position of the DVE. The (0, 0) co-ordinate
represents the top left corner of the DVE move after the video has been cropped.
Horizontal Size: The horizontal size of the end frame can be defined by editing a specific number of
pixels or a percentage of the full horizontal pixel length.
Vertical Size: The vertical size of the end frame can be defined by editing a specific number of lines or a
percentage of the total number of vertical lines.
Full Screen: This checked if you want the ending frame to be full screen.
Crop Frame: This will allow the user to crop a portion of the end frame.
7.2.2.3. Border
Note: DVE Border is currently NOT supported.
This allows the user to define border around the DVE move. The border of the DVE can be sharp with
no colours, or with a soft edge with a colour. This section configures the parameter for the border.
