RESTRICTED USE ONLY Fargo Electronics, Inc.
HDP 800 Series Card Printer/Encoders Service Manual (Rev. 5.0)
157
Attaching the Card Lamination Module (continued)
Step Procedure
8 In all, eight (8) screws, the Card Output Hopper's main enclosure and the Card
Output Bin should now be removed from the Printer. (Note: Set these items
aside.)
9 Set the Card Lamination Module just to the left of the Printer and at a slight
angle as shown.
Continued on the next page
