FlexDSL ORION 3 - Page 15

User Manual LTU Orion 3
15
Remote Power and Wetting
Current Supply Modes
Voltage
Current
Restrictions
Remote Power Source
120VDC
60, 90
125mA not
available for
120VDC
XM60 DSL-1
XM38 DSL-2
XM65 DSL-3
XM35 DSL-4
XM52 DSL-1
XM54 DSL-2
XM51 DSL-3
XM53 DSL-4
XM42 DSL-1/2
XM50 DSL-3/4
XM47 DSL-1/2
XM48 DSL-3/4
XM55 DSL-1
XM58 DSL-2
XM56 DSL-3
XM57 DSL-4
Configuration SW:
POWER [OFF/ON] N
Remote Power Source
200VDC
60, 90, 125mA
200VDC only, if half
of the SHDSL
channels are used
XM60 DSL-1
XM38 DSL-2
XM65 DSL-3
XM35 DSL-4
XM52 DSL-1
XM54 DSL-2
XM51 DSL-3
XM53 DSL-4
XM42 DSL-1
XM50 DSL-2
XM47 DSL-1
XM48 DSL-2
XM55 DSL-1
XM58 DSL-2
XM56 DSL-3
XM57 DSL-4
Configuration SW:
POWER [OFF/ON] N
Wetting Current Supply
47VDC
3.5mA
XM60 DSL-1
XM38 DSL-2
XM65 DSL-3
XM35 DSL-4
XM52 DSL-1
XM54 DSL-2
XM51 DSL-3
XM53 DSL-4
XM42 DSL-1/2
XM50 DSL-3/4
XM47 DSL-1/2
XM48 DSL-3/4
XM55 DSL-1
XM58 DSL-2
XM56 DSL-3
XM57 DSL-4
Wetting Current Consumption
Termination
XM60 DSL-1
XM38 DSL-2
XM65 DSL-3
XM35 DSL-4
XM52 DSL-1
XM54 DSL-2
XM51 DSL-3
XM53 DSL-4
XM42 DSL-1/2
XM50 DSL-3/4
XM47 DSL-1/2
XM48 DSL-3/4
XM55 DSL-1
XM58 DSL-2
XM56 DSL-3
XM57 DSL-4
Table 3.3 Possible remote power and wetting current supply modes
WARNING
IN CENTRAL EUROPE IT IS STRICTLY PROHIBITED TO SETUP THE
REMOTE POWER TO MORE THAN 120VDC. EXCEPTIONS WITH MORE
THAN 120VDC HAVE TO BE INSTALLED ACCORDING THE SAFETY
STANDARD EN 60950.
When a dual/quad DSL channel LTU is connected to NTU/RR and LTU and the remote power
feature is used, a DCL alarm may appear. In this case we recommend to remove the jumpers for
the corresponding remote power channel to the LTU (XM60, XM38, XM65 or XM35).
WC
60mA
90mA
125mA
WC
60mA
90mA
125mA
WC
60mA
90mA
125mA
WC
60mA
90mA
125mA
