5.3-2 Section 5: 9500B Procedure Mode - Access Guide
Final Width = 215mm
Descriptions assume 9500B/1100
5.3.3.4 Select and Insert the
Procedure Card which
contains the Procedure for
the Subject UUT Model
a. No Procedure Card in Slot, and no
Procedures Downloaded
Up to now, there has been no need to use the
Procedure memory card. After this point, the
9500B needs to extract information from the
card, so the card required for the UUT must be
inserted into PCMCIA SLOT 1, and pushed
firmly home. But first:
Examine the Memory Card
The 68-way socket pins can be seen on the end
of the card to be inserted:
In this case, insert the card required for the
UUT into PCMCIA SLOT 1, push gently
home, and press the 'NEW CARD' screen key
for the sequence to continue.
The 9500B will transfer to the 'Select
MANUFACTURER' menu screen if more than
one manufacturer is listed in the procedure
card, or to 'Select MODEL' screen if only one
manufacturer is listed.
b. No Procedure Card in Slot, but a UUT
Model's Procedures Resident in RAM
If, on a previous occasion since the most-
recent power-on, a UUT model was selected
from the Select Model screen menu, the 9500B
will have downloaded all the procedures for
the selected model into internal RAM.
If, on this occasion, no Procedure memory
card has yet been inserted into the slot, and
procedures are still resident in the RAM, (see
5.3.3.6), then a message similar to the following
will appear on the screen:
Keep this side on top
Insert this end into 9500 slot
Missing key
Missing key
underneath
Top
Socket pins this end
Insert
Insert the Card
When inserting, the missing key must be located
underneath the card on the right front:
If no Procedure Card has yet been inserted into
the slot, and no procedure is at present resident
in the RAM, (see 5.3.3.6), then the following
message will appear on the screen:
For a different model, insert the card required
for the UUT into PCMCIA SLOT 1, push
firmly home, and press the 'NEW CARD'
screen key for the sequence to continue.
After pressing 'NEW CARD', the 9500B will
transfer to the 'Select MANUFACTURER'
menu screen if more than one manufacturer is
listed in the procedure card, or to 'Select
MODEL' screen if only one manufacturer is
listed.
ABORT returns to the 'Select USER NAME
...' screen.
Refer to paras 5.3.3 13, Fig 5.3.2.
A choice is given: whether to use the loaded
procedures, or to insert a new card to load a
different model's procedures.
For the same model, merely press the
'MODEL' screen key and the 9500B will
transfer to the 'Enter the SERIAL NUMBER
...' screen.
TODAY'S DATE TIME
NEW
CARD
There are no previously loaded models.
Insert a procedure card and then press
NEW CARD to continue.
ABORT
TODAY'S DATE TIME
NEW
CARD
The MODEL X model
has been loaded previously.
Press MODEL to use this model or
insert a procedure card and then press
NEW CARD to continue.
ABORTMODEL
