Section 3: Model 9500B Controls: Modes of Operation 3-11Descriptions assume 9500B/1100
3.4.3.6 'Power-up mode'
Mode Selection at Power-on
Users can determine which mode will be
selected automatically at power-on, choosing
between Procedure mode and Manual mode.
The 9500B cannot be made to power-up in any
other mode.
To set the power-up default mode use the
procedure in the column on the right.
1. For access to change the default mode,
press the POWER UP MODE screen key
on the 'Present Settings' screen.
2. This transfers to a 'Configuration' screen
to change 'The default power-on mode':
TODAY'S DATE TIME
Configuration
The current printer type is
indicated by the highlight.
Use the softkeys to select
another.
EXIT
BUBBLE
JET
EPSON
USER
DEFINED
DISABLE
DESK JET
3. Use numeric entry to set the required bus
address number. Type the number on the
keypad, then press the ↵ key.
4. Press EXIT to return to the 'Present Settings'
screen.
For second address (5000-series emulation),
refer to Section 6, Appendix F.
3.4.3.5 'Printer'
Printer Operation (Procedure Mode and
Test Mode only)
Using the Procedure mode print facility, the
9500B can deliver a printed certificate, whose
style is also determined in Configuration mode.
In Test mode, test results can also be printed —
in a pre-determined format. The results are
stored until the print command is given after
the test is over. The printer does not need to be
selected in Configuration mode, unless the
results print is required to conform to the
layout of a particular type of printer.
The printer is set up only when an attempt is
made to print, following two types of occasion:
a. printer type is changed in Config mode;
b. 9500B is powered on.
Printer Type Selection
1. For access to select and enable a particular
printer type (or one using the same
formatting), press the PRINTER screen
key on the 'Present Settings' screen.
2. This transfers to a 'Configuration' screen
to change 'The current printer type':
3. Power-on default is DISABLE.
Use the screen keys to select the type of
printer on the interface, or to disable direct
printing.
4. EXIT returns to the 'Present Settings' menu
screen.
User Defined Printer Type
5. If the type of printer you are using does not
conform to one of those listed, press the
USER DEFINED screen key. This
transfers to a 'Configuration' screen
designed to enter the initialisation control
codes for your printer:
(continued overleaf)
6. Obtain the initialisation control codes from
your printer's operating manual. If
necessary, convert the codes to decimal.
Use the 9500B keypad to type the decimal
codes, separated by spaces (→): the new
string replaces the old. Press the ↵ key.
6. EXIT returns to the 'current printer type'
screen.
3. To change the default, press the required
screen key on the right.
4. Press EXIT to return to the 'Present Settings'
screen
The new default will be incorporated into the
list. Next time the line power is turned from
OFF to ON, the 9500B will power-up in the
selected mode.
TODAY'S DATE TIME
Configuration
Enter the initialisation
control codes in decimal
and confirm with enter.
The current control code string is
:
(string appears here
eg 27 116 1 18 15)
Enter a new control string
:
EXIT
TODAY'S DATE TIME
Configuration
Change by direct edit only.
EXIT
9500B address=
22
IEEE 488 ADDRESSES
2nd address inactive
9500B
5ØØØ
SERIES
TODAY'S DATE TIME
Configuration
The default power-on mode is
indicated by the highlight.
Use the softkeys to select
another.
EXIT
PROC
MANUAL
