3-16 Section 3: Model 9500B Controls: Modes of Operation Descriptions assume 9500B/1100
TODAY'S DATE TIME
3.4.3.19 'Certificate'
Results Certificates
In Procedure mode, three styles of printed
certificate are available:
Style 1
This provides full information about each point
tested, including applied and target values,
spec limits and UUT error, % error pass/fail
and test uncertainty ratio between 9500B and
UUT.
Style 2
This is a shorter form of certificate, showing
only the applied and target values, and the
9500B absolute uncertainty.
Style 3
This certificate is similar to Style 1, and has
been added to accommodate the wider spec
limits encountered during oscilloscope
calibration, expressed in percentages rather
than ppm.
Users are given the facility, in Configuration
mode, to change the style of certificate to be
printed.
1. For access to allow the certificate
formatting to be altered, press the CERT
DETAILS screen key on the second
'Present Settings' screen.
2. This transfers to what we shall refer to as
a 'CERT DETAILS' screen:
3. The 'CERT DETAILS' screen allows users
to design a certificate by adjusting or
selecting characteristics via screen keys
on the right (refer to paras 3.4.3.20 to
3.4.3.28).
4. The EXIT screen key reverts to the second
'Present Settings' screen.
3.4.3.20 'CERT STYLE'
1. For access to select the certificate style,
press the CERT STYLE screen key on the
'CERT DETAILS' screen. This transfers
to 'The certificate type' screen, which allows
the style of certificate to be selected:
2. Press the key on the right which represents
the required style of certificate.
3. Press the EXIT screen key to revert to the
CERT DETAILS screen.
3.4.3.21 'PAGE SETUP'
1. To set up the certificate page, press the
PAGE SETUP screen key on the 'CERT
DETAILS' screen. This transfers to what
we shall refer to as a 'PAGE SETUP'
screen, which allows users to design the
certificate page, using the keys on the
right:
2. Press the key on the right which describes
the attribute to be changed.
3. The EXIT screen key to revert to the
CERT DETAILS screen.
3.4.3.22 'Start page number'
1. To change the certificate start page number,
press the START PAGE screen key on the
'PAGE SETUP' screen. This transfers to
the 'Current start page' screen:
2. Use Direct edit to enter the new start page
number.
3. Press the ↵ screen key to confirm the new
page number and return to the 'PAGE
SETUP' menu screen. The new page
number will appear on the 'Present settings'
list.
4. The EXIT screen key reverts to the PAGE
SETUP screen without changing the start
page number.
TODAY'S DATE TIME
Configuration
The current start page is 1
Enter a new page
:
EXIT
TODAY'S DATE TIME
Configuration
The certificate type is
indicated by the highlight.
Use the softkeys to select
another.
EXIT
STYLE 1
STYLE 2
STYLE 3
Configuration
Present Settings:
Certificate Style 1
Start page number 1
Page length 66
Pass indicator ON
Appended message
EXIT
CERT
STYLE
PASS
INDIC
APPEND
MESSAGE
LAB
DETAILS
PAGE
SETUP
CERT DETAILS Screen Layout
TODAY'S DATE TIME
Configuration
Present Settings:
Start page number 1
Page length 66
Header size Ø
Footer size 1
EXIT
START
PAGE
HEADER
SIZE
FOOTER
SIZE
PAGE
LENGTH
PAGE SETUP Screen Layout
