Infratec™ 1241 Grain Analyzer
5:26 Service Manual 1001 5015 / Rev. 4
7. Disconnect the eight cables from the DSP Board.
Fig. 5:28 DSP Board
P6 Power Supply P12 Monochromator Shutter Board
P7 Inverter Interface Board P13 Detector
P8 Monochromator Encoder P14 I2C Bus
P9 Monochromator Grating Motor P15 I2C Bus
