Infratec™ 1241 Grain Analyzer
Service Manual 1001 5015 / Rev. 4 3:15
11. Fasten the cover plate to the deflector and adjust. Then fasten the screws holding
the deflector.
Fig. 3:27
12. Use the three screws that were holding the bottom plate to cover the screw holes
(one screw is not shown below).
Fig. 3:28
