Infratec™ 1241 Grain Analyzer
4:16 Service Manual 1001 5015 / Rev. 4
Line description including typical value Units
Min.
limit
Max.
limit
Comments
SelfTest/1241xxxx/Detector/SerialNumber=String, 00000015
One measurement (with closed shutter and lamp turned off) per gain step is performed, where 5000 points are read.
The criteria for this test is that the mean value in all steps should be between 50-2000. Measurements are made in 15 steps.
The standard deviation should be max.(see highlighted values).
SelfTest/1241xxxx/Detector/gain1/Min=Number, 499 bits 5
SelfTest/1241xxxx/Detector/gain1/Max=Number, 500 bits
SelfTest/1241xxxx/Detector/gain1/Mean=Number, 500 bits 50 2000
SelfTest/1241xxxx/Detector/gain1/StdDev=Number, 0.4943 bits 2.0
SelfTest/1241xxxx/Detector/gain1/Temp=Number, 24 real 0 60
SelfTest/1241xxxx/Detector/gain2/Min=Number, 499 bits 5
SelfTest/1241xxxx/Detector/gain2/Max=Number, 500 bits
SelfTest/1241xxxx/Detector/gain2/Mean=Number, 500 bits 50 2000
SelfTest/1241xxxx/Detector/gain2/StdDev=Number, 0.4943 bits 2.0
SelfTest/1241xxxx/Detector/gain2/Temp=Number, 24 real 0 60
SelfTest/1241xxxx/Detector/gain3/Min=Number, 499 bits 5
SelfTest/1241xxxx/Detector/gain3/Max=Number, 500 bits
SelfTest/1241xxxx/Detector/gain3/Mean=Number, 500 bits 50 2000
SelfTest/1241xxxx/Detector/gain3/StdDev=Number, 0.4943 bits 2.0
SelfTest/1241xxxx/Detector/gain3/Temp=Number, 24 real 0
SelfTest/1241xxxx/Detector/gain4/Min=Number, 499 bits 5
SelfTest/1241xxxx/Detector/gain4/Max=Number, 500 bits
SelfTest/1241xxxx/Detector/gain4/Mean=Number, 500 bits 50 2000
SelfTest/1241xxxx/Detector/gain4/StdDev=Number, 0.4943 bits 2.0
SelfTest/1241xxxx/Detector/gain4/Temp=Number, 24 real 0 60
SelfTest/1241xxxx/Detector/gain5/Min=Number, 498 bits 5
SelfTest/1241xxxx/Detector/gain5/Max=Number, 502 bits
SelfTest/1241xxxx/Detector/gain5/Mean=Number, 500 bits 50 2000
SelfTest/1241xxxx/Detector/gain5/StdDev=Number, 0.4943 bits 2.0
SelfTest/1241xxxx/Detector/gain5/Temp=Number, 24 real 0 60
SelfTest/1241xxxx/Detector/gain6/Min=Number, 498 bits 5
SelfTest/1241xxxx/Detector/gain6/Max=Number, 502 bits
SelfTest/1241xxxx/Detector/gain6/Mean=Number, 500 bits 50 2000
SelfTest/1241xxxx/Detector/gain6/StdDev=Number, 0.4943 bits 2.0
SelfTest/1241xxxx/Detector/gain6/Temp=Number, 24 real 0 60
SelfTest/1241xxxx/Detector/gain7/Min=Number, 498 bits 5
SelfTest/1241xxxx/Detector/gain7/Max=Number, 502 bits
SelfTest/1241xxxx/Detector/gain7/Mean=Number, 500 bits 50 2000
SelfTest/1241xxxx/Detector/gain7/StdDev=Number, 0.4943 bits 2.0
SelfTest/1241xxxx/Detector/gain7/Temp=Number, 24 real 0 60
