Infratec™ 1241 Grain Analyzer
Service Manual 1001 5015 / Rev. 4 4:17
Line description including typical value Units Min. Max. Comments
SelfTest/1241xxxx/Detector/gain8/Min=Number, 495 bits 5
One measurement (with closed shutter and lamp turned off) per gain step is performed, where 5000 points are read.
The criteria for this test is that the mean value in all steps should be between 50-2000. Measurements are made in 15 steps.
The standard deviation should be max.(see highlighted values).
SelfTest/1241xxxx/Detector/gain8/Max=Number, 505 bits
SelfTest/1241xxxx/Detector/gain8/Mean=Number, 500 bits 50 2000
SelfTest/1241xxxx/Detector/gain8/StdDev=Number, 0.8220 bits 3.0
SelfTest/1241xxxx/Detector/gain8/Temp=Number, 24 real 0 60
SelfTest/1241xxxx/Detector/gain9/Min=Number, 495 bits 5
SelfTest/1241xxxx/Detector/gain9/Max=Number, 505 bits
SelfTest/1241xxxx/Detector/gain9/Mean=Number, 500 bits 50 2000
SelfTest/1241xxxx/Detector/gain9/StdDev=Number, 0.8220 bits 3.0
SelfTest/1241xxxx/Detector/gain9/Temp=Number, 24 real 0 60
SelfTest/1241xxxx/Detector/gain10/Min=Number, 495 bits 5
SelfTest/1241xxxx/Detector/gain10/Max=Number, 505 bits
SelfTest/1241xxxx/Detector/gain10/Mean=Number, 500 bits 50 2000
SelfTest/1241xxxx/Detector/gain10/StdDev=Number, 0.8848 bits 4.0
SelfTest/1241xxxx/Detector/gain10/Temp=Number, 24 real 0 60
SelfTest/1241xxxx/Detector/gain11/Min=Number, 492 bits 5
SelfTest/1241xxxx/Detector/gain11/Max=Number, 508 bits
SelfTest/1241xxxx/Detector/gain11/Mean=Number, 500 bits 50 2000
SelfTest/1241xxxx/Detector/gain11/StdDev=Number, 1.0310 bits 5.0
SelfTest/1241xxxx/Detector/gain11/Temp=Number, 24 real 0 60
SelfTest/1241xxxx/Detector/gain12/Min=Number, 490 bits 5
SelfTest/1241xxxx/Detector/gain12/Max=Number, 525 bits
SelfTest/1241xxxx/Detector/gain12/Mean=Number, 510 bits 50 2000
SelfTest/1241xxxx/Detector/gain12/StdDev=Number, 3.0721 bits 9.0
SelfTest/1241xxxx/Detector/gain12/Temp=Number, 24 real 0 60
SelfTest/1241xxxx/Detector/gain13/Min=Number, 525 bits 5
SelfTest/1241xxxx/Detector/gain13/Max=Number, 650 bits
SelfTest/1241xxxx/Detector/gain13/Mean=Number, 575 bits 50 2000
SelfTest/1241xxxx/Detector/gain13/StdDev=Number, 6.1721 bits 17.0
SelfTest/1241xxxx/Detector/gain13/Temp=Number, 24 real 0 60
SelfTest/1241xxxx/Detector/gain14/Min=Number, 525 bits 5
SelfTest/1241xxxx/Detector/gain14/Max=Number, 750 bits
SelfTest/1241xxxx/Detector/gain14/Mean=Number, 650 bits 50 2000
SelfTest/1241xxxx/Detector/gain14/StdDev=Number, 18.6891 bits 30.0
SelfTest/1241xxxx/Detector/gain14/Temp=Number, 24 real 0 60
SelfTest/1241xxxx/Detector/gain15/Min=Number, 500 bits 5
SelfTest/1241xxxx/Detector/gain15/Max=Number, 1000 bits
SelfTest/1241xxxx/Detector/gain15/Mean=Number, 700 bits 50 2000
SelfTest/1241xxxx/Detector/gain15/StdDev=Number, 25.6891 bits 60.0
SelfTest/1241xxxx/Detector/gain15/Temp=Number, 24 real 0 60
