DMT-8vl Owner's Manual (Names and Functions)
51. R ecorder Out jacks [RECORDER OUT 1-0] (Connector: RCA pin J»ck)
These analog connectors arc used to output the recorder Track 1-8 signal directly.
When you are using the DMT-8vt as a dedicated recorder, connect these jacks to the
INPUT jacks of the external mixing console.
• Rflfor 10 pa go *74* tor mere infcrmatcr on using tha OMT-tn. as a dsdealad recorder
52. R ecorder In jack [RECORDER IN 2/W8,1/3/V7] (Connector RCA pin jack)
These connectors are used to route the external signal directly to the recorder section
of the DMT-8VI when you are using only the recorder section of the unit. The signal
will be sent to four tracks simultaneously. Input signal at RECORDER IN 1/3/5/7 is
routed to Tracks 1/3/5/7; input signal at 2/4/6/8 is routed to Tracks 2/4Z6/8.
Connect the OUTPUT Jack of the external mixing console here.
<Nota>
Whan you correct r» pug into ora of to DMT-to't RECORDER IN yack, the Master Mara UR wil
bo dtsoblod tor mcordng. anca IT# corroclad dewca has prtodty * you wi ah to uta tha DMT-Bw'4
motor tone*or tor racordnq. neke aura that you mmov* arvy plugs from N RECORDER W Jacks
• Ralor to peg# *7T tor mom i n torm—or or tang tot DMT*0vi aa a dedicated mcordcr
53. D ata Output connector [DATA OUT] (Connector: OPTICAL)
Use this connector to connect and save DMT-8 vl data to a DAT machine.
This connector Is also used to record digital data from the DMT-8VL to an external
digital device.
• Ralar to paga 117* tor mom idomaaor about %avrq dau
• Ralar to pagas *82 ard 64" tor more ntormatton about digits raoonJng. I
54. D ata Input connector [DATA IN] (Connector: OPTICAL)
Use this connector to load song data (audio + setup data) stored on a DAT machine
to the DMT-8 vl You can also use this for digital recording from an external digital
device, such as a CD player or a MD player, to the DNfT-Bvu
f* Ralar to pegs ’ll 7* tor mom totormadon about loadhg terq d*U
• Rater to page* *82 and 64’ tor mora ntormaOon about dig fat racordng I
55. P unch In/Out Jack [PUNCH IN/OUT] (Connector: STEREO PHONE Jack)
Connecting an optional foot switch will let you control punch Ill/out (and rehearsal)
recording. Use the Fostex Model 8051 foot switch.
f* Refer to page ‘83* tor tatormaicn about punch irVout raccrdng using a toot nwlch. |
56. MIDI INKXTT connectors [MIDI INPUT/OUTPUT] (Connector: DIN 5-pin)
MIDI INPUT:
Connect the MIDI OUT connector from an external Mll>! device hen*.
Sending the MMC (MIDI Machine Control) commands or FEX (Fostex System Exclusive
messages) allows you to control the DMT-8vi remotely.
MIOt OUTPUT:
Connect the MIDI IN connector on the external MIDI device here.
This connector win output MTC (MIDI timecode). MMC (MID! Machine Control) response.
MIDI clock signal, and FEX (Fostex System Exclusive messages).
57. Power switch
This switch turns the main power to the DNTT-8 vl on/off.
<W»mlng>
Batora hiring off tva power to T* DMT-Sn-. baser# to qufl SETUP moda and make sura that the im* to in I
slop mods Do nottum oft Vm power lha DMT-e*. is accessing the herd dtsk tho K) ACCESS I
LEO* It Of b»f>«ng) Oewmrtaa, mconM a*i may be tool forever |
26
