DMT-SVL Owner's Manual (Recording/Playback)
2. MIDI Clock synchronization system
In this section, we will learn how to insert a time signature at any location of the
vong and set the tempo using the internal Program Tempo Map, In order to
synchronize an external stand-alone MTDI sequencer to the MIDI Qock as a slave
machine.
You can use all eight tracks on the DMT-Bvi < unlike conventional tape multitrack
recorders, on which you must sacrifice one track for the FSK signal).
Also, you can route the signal Irom the INPUT jacks and the signal from the recorder
to route alternately to the INPUT faders and the MON knobs using the INPUT SEL
switches. (This Is called Alternate Mix function.)
For example, you can route the recorder signal to the INPUT faders, route maximum
eight MIDI sound sources connected to the INPUT tacks to the MON knobs, and
route the MON OUT L/X signal to RECORDER IN.
In this way, you can mix down maximum 16 channel sound sources without an
external mixing console (parallel twin mix).
* Set the DMT-Bw to tha dotaiJt wOng
' Max* slcq mat you have already aoectod an appropriate Proj'arr rubber.
-
Connecting an external device
1 Connect the DMT-Bwi MIDI OUT connector to the MIDI IN connector on the MIDI sequencer.
2 Set the MIDI sequencer to "MIDI Clock Sieve mode’ and connect the MIDI sound source
that plays sequence date to the INPUT Jack of the DMT-eve.
This MIDI sound source niJI not be retarded (it mil only be ptoyed hack, synchronizing to
a MIDI sequencer). Set the mixer to that you can monitor the sound.
3 Connect the effect unit if necessary.
(AUX SESD 1 -> Effect unit 1 -> AUX RTS 1. AUX SEND 2 -» Effect unit 2 •> AUX RTS 2)
MIDI SYNC OUT settings
1. Set ’MIDI SYNC OUT In Setup mode to "MlOt Clock (CtocK) OUT.”
If you mth to use the metronome function, set "CLICK* in Setup mode to OS.
|* RMsr lo page® *125* of IT# SETUP rod® fraction lor delete J
Creating a Tempo Map
i
1 Set ■ time signature for each measure using ths "BAR " parameter In Setup mode.
Then. Art the tempo for each ber/beu location using the "TEMPO* parameter in Setup
mode.
• Rafar to page *1 IT of me SETUP mode aoction toe dotais
2 Run the DMT-hn. In record mode to confirm that the MIDI sequencer will synchronize to
the Tempo Map. (You do not need to record any particular sound because this step just
makes an already-recorded <Ssk area.) (ft data has already bean recorded up to the end
point of the song, just play back tha DMT-*i_) Set the Time Base to "BAR/ /CUT to
check whether tha playback position on the MIOI sequencer matches that on the DMT-Bn_
Overdubbing
1 Overdub performance date to Tracks 1-8 while accompanying the synchronizing MIDI
source output (as If the source was data already recorded on the track). Alternatlvaly.
you can actually record the MIDI sound source In a track as a guide or accompaniment
track.
67
