Tips for troubleshooting
101
Correcting the moistening felt position
on the rocker
• Slightly tilt the rocker and pull it off in an
obliquely upward direction.
Caution! Make sure to always hold the leg
spring on the pin with one hand while posi-
tioning the moistening felt. This will prevent
the leg spring from jamming or jumping out.
• Push the long moistening felt side fully
underneath the clamping strip such that
– the felt’s recesses are perfectly aligned
with the rocker stop edge and
– both moistening felt outer edges uni-
formly project over the rocker edge by
approximately 0.04 - 0.08" (1 - 2 mm).
See illustration.
• Carefully displace the moistening felt in the
clamping strip if necessary.
• Reattach the rocker on the sealer
(see page 92).
Hold leg spring
in place!
Moistening felt
Projection
0.04 - 0.08"
Moistening felt correctly
positioned:
Aligned with
stop edge
