SECTION 4 - MECHANICAL OVERHAUL
F32 SERIES
Base - April 2009 Print P2D32F005 E
DATA - ASSEMBLY SLACKS
Type 4CYLINDERS
CYLINDER UNIT AND CRANKSHAFT COMPONENTS mm

1
X
Cylinder barrels 1
1
99 to 99.02
0.4

1
X

2
Spare pistons
type:
Size X
Outside diameter  1
Pin housing  2
10
98.908 to 98.918
36.003 to 36.009
Piston — cylinder barrels 0.082 to 0.112
Piston diameter  1 0.4
X
Piston protrusion X -0.22 ÷ +0.07
3

Piston pin  3 35.996 to 35.999
Piston pin — pin housing 0.004 to 0.013
