40
SECTION 3 - INDUSTRIAL APPLICATION
F32 SERIES
Base - April 2009 Print P2D32F005 E
Ref. Description
1 PWM output signal for EGR solenoid valve
2 -
3 ECU Mass
4 Mass for pre-heating (on) warning light
5 ECU supply (+ 15)
6 K line signal
7 Intake manifold temperature and pressure sensor supply (5)
8 EGR solenoid valve feed (potentiometer)
9 K line mass
10 EGR solenoid valve mass (potentiometer)
11 Cooling liquid temperature sensor mass, on thermostat unit
12 Air pressure and temperature sensor mass
13 Engine revolutions redundancy signal
14 E.C.U. supply (+30)
15 Pre-heating remote control switch
16 Engine high temperature warning light
17 Diagnosis warning light
18 Start
19 EGR solenoid valve position signal
20 Cooling liquid temperature sensor, on thermostat unit
21 Air temperature sensor signal
22 Pressure sensor signal, on intake manifold
23 Negative from engine drive shaft impulse transmitter
24 Engine drive shaft transmitter mass
25 Positive from engine drive shaft impulse transmitter
Pin out EGR E.C.U.
