FPT F32 MNS - Engine Oil Filter

8
SECTION 1 - GENERAL SPECIFICATIONS
F32 SERIES
Base - April 2009 Print P2D32F005 E
1. Protective cover - 2. Cartridge
Booster pressure: 20 bar (ISO 4548/3)
Dynamic pressure: 0-15 bar (1Hz) > 50,000 cycles (ISO 4548/5)
Operating temperature: -40 / + 140 ˚C
Torque wrench setting: 30 ± 3 Nm
Maximum flow: 50 l/min.
Load loss at the end of life cycle: 2.5 bar
Accumulation: > 15 gr with 2.5 bar load loss (ISO 16889)
Figure 7
119406
Engine oil filter
Revi - 12.2012
