SECTION 3 - INDUSTRIAL APPLICATION
F32 SERIES
Base - April 2009 Print P2D32F005 E
Calibration
80 ˚C
[k]
Calibration
20 ˚C
[k]
Calibration
10 ˚C
[k]
0.304 - 0.342 2.262 - 2.760 8.244 - 10.661
Characteristics
Working temperature range
- Connector’s side -40 ˚C ÷ 130 ˚C; 150 ˚C for periods < 10 min.
- Bulb’s side on engine -40 ˚C÷140˚C
Voltage 6÷28V
Engine cooling liquid temperature sensor (for F5CE5454 engines)
The sensor is fitted on the thermostat unit. It consists of two NTC thermistors with two reophores.
Figure 94
119454
