FPT F32 MNS - Pipe Layout

118976
1. Injector feed pipe - 2. Fuel exhaust pipe from injectors - 3. Supply rotary pump - 4. Union for pressure gauge pipe within
LDA intake manifold - 5. KSB thermal bulb - 6. Solenoid valve - 7. Injector.
PIPE LAYOUT
Figure 2
4
SECTION 2 - SUPPLY
F32 SERIES
Base - April 2009 Prin t P2D 32F005 E
