SECTION 1 - GENERAL SPECIFICATIONS
7
F32 SERIES
Print P2D32F005 E Base - April 2009
PUMP SPECIFICATIONS
Rotating speed 750 rpm - 4200 rpm
Feed pressure 2Bar-4Bar
Rated flow 12.2 l/min - 75.9 l/min
Oil type SAE 20/30
Max. oil temperature 80 C
1. Main gear - 2. Secondary gear - 3. Pump unit - 4. Drive shaft - 5. Secondary shaft
6. Cover - 7. Internal rotor - 8. External rotor - 9. Bush.
Figure 6
119405
Oil pump
