FPT F32 MNS - Heat Exchanger

119408
Figure 13
The heat exchanger within the engine cooling system has the duty to control the engine oil temperature, reducing it by absorbing
heat throughout the engine cooling liquid.
HEAT EXCHANGER
SECTION A-A
SECTION B-B
SECTION 1 - GENERAL SPECIFICATIONS
13
F32 SERIES
Print P2D32F005 E Base - April 2009
