FPT F32 MNS - SECTION 3 - INDUSTRIAL APPLICATION

SECTION 3 - INDUSTRIAL APPLICATION
1
F32 SERIES
Pri nt P2D32F005 E Base - April 2009
SECTION 3
Industrial application
Page
MAIN SPECIFICATIONS 3..................
PART ONE -
MECHANIC AL COMPONENTS 5.........
ENGINE DISASSEMBLY ON BENCH 7........
- Cylinder 1 T.D.C. search 8.................
- BOSCH VE 4/12F Pump 9.................
- Timing gearc a se 12........................
- Rear side component assembly 14...........
- Flywheel assembly 14......................
- Front side component installation 15..........
- Timing 16...............................
- Piston projection measurement 17...........
- Checks and inspections 25..................
- Rocker cover blow-by removal and refitting 26..
- Rotary feed pump disassembly and assembly
procedure 30............................
- Injection pump static advance control on engine at
cylinder 1 TDC 33........................
- Power takeoff 33.........................
PART TWO - ELECTRICAL EQUIPMENT 35...
ENGINE CABLE FOR EXTERNAL EGR SYSTEM
(FOR F5CE5454 ENGINES) 37..............
EXTERNAL EGR E.C.U. ELECTRICAL LAYOUT
(FOR F5CE5454 ENGINES) 38..............
- External EGR E.C.U.
(for F5CE5454 engines) 39.................
- Pin out EGR E.C.U. 40.....................
KSB - BOSCH PUMP CONNECTION CABLE 41.
