Figure 32
Timing
124497
- Fit tool (1) 99360330 to flywh eel housing to rotate the
flywheel (must be used with a suitable wrench).
119125
Figure 33
- Seize the 45˚ bevel tooth (1) of the engine drive sh aft
gear with t he timing gear t ooth marked with two
notches (2), as shown in the figure.
- Rotate the camshaft keeping the timing gear fix until the
camshaft’s pin fits into the relevant housing within the
timing gear.
- Screw the screws of the transmission gear without fully
tightening them.
- With magnetic base co mparator, check the clearance
among the engine sh aft gear and t he cam sh aft gear: it
must be 0.068 ÷ 0.168 mm.
- Screw the fastening screws (1) of the t ransmission gear.
Position the engine drive shaft at T.D.C. of cylinder 1 rotating
the flywheel un t il achieving t h e following c on ditions:
- the notch (1) is visible from the in spection hole;
- to ol 99360612 should be fitted through the carter into
the port on the flywheel.
Remove tools and tighten the previously loosened plate
screws.
- Loosen the screws of the plate in which tool 99360612
(1) is to be fitted.
132006
133189
Figure 34
Figure 35
16
SECTION 3 - INDUSTRIAL APPLICATION
F32 SERIES
Base - April 2009 Prin t P2D 32F005 E
