Figure 16
124466
BOOSTING
For engines without external EGR
The boosting system is composed of the following parts:
- Air filter;
- Turbosupercharger.
- An ”intercooler” radiator (if fitted)
Sucked air
Heated compressed air
Engine exhaust gas
16
