FPT F32 MNS - Page 122

6
SECTION 4 - MECHANICAL OVERHAUL
F32 SERIES
Base - April 2009 Print P2D32F005 E
Type 4CYLINDERS
CYLINDER UNIT AND CRANKSHAFT COMPONENTS
mm
12
S
1
S
2
Crankshaft bearing pins
No. 1-2-3-4  1
No. 5  1
Bigendbearingpins  2
76.182 to 76.208
83.182 to 83.208
64.015 to 64.038
Crankshaft half bearings S 1
Big end half
bearings S 2
2.165 to 2.174
1.877 to 1.883
3

Crankshaft supports
No. 1-2-3-4  3
No. 5 3
80.588 to 80.614
87.588 to 87.614
Half bearings — Journals
No. 1-2-3-4
No. 5
0.064 to 0.095
0.059 to 0.100
Half bearings - Crankpins 0.033 to 0.041
Main half bearings
Big end half bearings
0.127; 0.254; 0.508
1
X
Crankshaft pin for
shoulder X 1
31.85 to 32.150
X 2
Crankshaft support for
shoulder X 2
32.50 to 32.55
Shoulder half-rings X 3 2.51 to 2.56
Engine drive shaft shoulder 0.095 to 0.270
