SECTION 4 - MECHANICAL OVERHAUL
9
F32 SERIES
Print P2D32F005 E Base - April 2009
Type 4CYLINDERS
CYLINDER HEAD — TIMING SYSTEM mm
1
Tappet cap housing
on block 1
15,000 ÷ 15,018
2
3
2
Tappet cap outside
diameter: 2
3
15.924 to 15.954
15.960 to 15.975
Between tappets and housings 0.03 to 0.068
Tappets -
1
Rocker shaft 1 18.979 to 19.000
2
Rockers 2 19.020 to 19.033
Between rockers and shaft 0.020 to 0.054
