103
EN-US
YIELD
OFF SET
Offset is an amount of energy (in Wh, kWh, or MWh) that can be added to the lifetime total
energy output of the inverter to give it a ‘head start.’
CALI.
Preset correction value, so that the data shown on the inverter display corresponds to the
calibrated data shown on the electric meter
IG NR
Number setting (address) of the inverter in
a setup comprising multiple solar inverters
linked together
Setting
- an OFFSET value for the total energy
display
- a measurement correction value for
the Day, Year and Total energy dis-
play
Setting range OFF SET / CALI.
Unit Wh / kWh / MWh
Setting range 5-digit + k... / M...
1 kWh = 1000 Wh
1 MWh = 1000000 Wh
Factory setting 0
Unit %
Setting range -5.0 - +5.0 in increments of 0.1
Factory setting 0
Unit -
Setting range 01 - 99 (100th inverter = 00)
Factory setting 1
IMPORTANT! Each inverter must be assigned its own address when connecting several
inverters in a data communications system.

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Fronius IG Plus A 3.0-1 UNI and is the answer not in the manual?

Fronius IG Plus A 3.0-1 UNI Specifications

General IconGeneral
AC nominal output3000 W
Max. apparent AC power3000 VA
Max. output current13 A
AC grid frequency50 / 60 Hz
THD<3%
Max. DC voltage500 V
Number of MPP trackers1
AC voltage range183 V - 264 V
DC input voltage range150 - 450 V
CoolingConvection
