Fronius IG Plus A 3.0-1 UNI User Manual

168
Relevant Standards and Directives
Relevant stan-
dards and direc-
tives
Grid Failure The standard measurement and safety procedures integrated into the inverter ensure that
the power feed is immediately interrupted in the event of a grid failure (shut-off by the utility
or damage to lines).
- UL 1741
- IEEE 1547
- IEEE 1547.1
- ANSI/IEEE C62.41
- UL 1699B Issue 2-2013
- FCC Teil 15 A & B
- NEC Article 690
- C22. 2 No. 107.1-01
(September 2001)

Fronius IG Plus A 3.0-1 UNI Specifications

General

AC nominal output	3000 W
Max. apparent AC power	3000 VA
Max. output current	13 A
AC grid frequency	50 / 60 Hz
THD	<3%
Max. DC voltage	500 V
Number of MPP trackers	1
AC voltage range	183 V - 264 V
DC input voltage range	150 - 450 V
Cooling	Convection
