Fronius IG Plus A 3.0-1 UNI User Manual

3
EN-US
General These operating instructions contain important instructions for the Fronius IG Plus that
must be followed during installation and maintenance of the inverter.
The Fronius IG Plus is designed and tested according to international safety requirements,
but as with all electrical and electronic equipment, certain precautions must be observed
when installing and/or operating the Fronius IG Plus.
To reduce the risk of personal injury and to ensure the safe installation and operation of
the Fronius IG Plus, you must carefully read and follow all instructions and safety instruc-
tions in these operating instructions.
Failure to follow these instructions and other relevant safety procedures may result in void-
ing of the warranty and/or damage to the inverter or other property!
Safety instruc-
tions
The following section "Safety instructions" contains various warnings. A Warning describes
a hazard to equipment or personnel. It calls attention to a procedure or practice, which, if
not correctly performed or adhered to, could result in damage to or destruction of part or
all of the Fronius inverter and/or other equipment connected to the Fronius inverter or per-
sonal injury.
Electrical installa-
tions
All electrical installations must be carried out in accordance with the National Electrical
Code, ANSI/NFPA 70, and any other codes and regulations applicable to the installation
site.
For installations in Canada, the installations must be done in accordance with applicable
Canadian standards.
IMPORTANT SAFETY
INSTRUCTIONS
SAVE THESE INSTRUCTIONS

Fronius IG Plus A 3.0-1 UNI Specifications

General

AC nominal output	3000 W
Max. apparent AC power	3000 VA
Max. output current	13 A
AC grid frequency	50 / 60 Hz
THD	<3%
Max. DC voltage	500 V
Number of MPP trackers	1
AC voltage range	183 V - 264 V
DC input voltage range	150 - 450 V
Cooling	Convection
