Fronius IG Plus A 3.0-1 UNI User Manual

21
EN-US
‘Fronius Arc
Blocker‘ plug-in
card
(15) 6 positive DC terminals (DC+)
(16) DC main switch
Item Description
Item Description
(1) Switch “Resume“
to reset the Fronius Arc Blocker
plug-in card after a detected arc
(2) Current sensor connection
(3) DC voltage measurement
(4) not available
(1) (2)
(3)
(4)

Fronius IG Plus A 3.0-1 UNI Specifications

General

AC nominal output	3000 W
Max. apparent AC power	3000 VA
Max. output current	13 A
AC grid frequency	50 / 60 Hz
THD	<3%
Max. DC voltage	500 V
Number of MPP trackers	1
AC voltage range	183 V - 264 V
DC input voltage range	150 - 450 V
Cooling	Convection
