Fronius IG Plus A 3.0-1 UNI User Manual

92
The Display Modes
The Display
Modes
Selecting a Dis-
play Mode
Accessing the menu level
Use the "left" (7) or "right" (6) keys to
select your preferred display mode (1)
- (4)
Press "Enter" (5)
The selected display mode is shown, e.g.,
"Day" display mode.
"Now" display mode ...... Displays real-time values
"Day" display mode ...... Displays values for power fed into the grid during that day
"Year" display mode ...... Displays values for the present calendar year - only avail-
able in combination with optional Fronius Datalogger
"Total" display mode ...... Displays values for power fed into the grid since the in-
verter was started for the first time
(7)
(1) (2) (3) (4)
(6) (5)
1
2
3
IMPORTANT! The "Year" menu option is
supported only when the optional Fronius
Datalogger is connected. This system up-
grade includes a real-time clock.

Fronius IG Plus A 3.0-1 UNI Specifications

General

AC nominal output	3000 W
Max. apparent AC power	3000 VA
Max. output current	13 A
AC grid frequency	50 / 60 Hz
THD	<3%
Max. DC voltage	500 V
Number of MPP trackers	1
AC voltage range	183 V - 264 V
DC input voltage range	150 - 450 V
Cooling	Convection
