Fronius IG Plus A 3.0-1 UNI User Manual

117
EN-US
Class 1 Status
Codes
Class 1 status codes are typically tempo-
rary. Their cause lies in the public grid.
The initial response of the inverter is to disconnect itself from the grid. The grid is subse-
quently checked for the stipulated monitoring period. If after the end of this period no fur-
ther defect is identified, your inverter resumes operating and feeding power into the grid.
IMPORTANT! The 2nd position x defines the exact network point for the following status
codes:
0 = several / all 3 phases
1 = L1
2 = L2
3 = L3
1x2
AC voltage too high
Behavior Grid conditions are thoroughly tested and as soon as they are
again within the permissible range, the inverter will resume
feeding power into the grid.
Remedy Check grid connections and fuses
Should the status code persist, you should contact your system
installer
1x3
AC voltage too low
Behavior Grid conditions are thoroughly tested and as soon as they are
again within the permissible range, the inverter will resume
feeding power into the grid.
Remedy Check grid connections, breakers and disconnect
Should the status code persist, you should contact your system
installer
1x5
AC frequency too high
Behavior Grid conditions are thoroughly tested and as soon as they are
again within the permissible range, the inverter will resume
feeding power into the grid.
Remedy Check grid connections and fuses
Should the status code persist, you should contact your system
installer
1x6
AC frequency too low

Fronius IG Plus A 3.0-1 UNI Specifications

General

AC nominal output	3000 W
Max. apparent AC power	3000 VA
Max. output current	13 A
AC grid frequency	50 / 60 Hz
THD	<3%
Max. DC voltage	500 V
Number of MPP trackers	1
AC voltage range	183 V - 264 V
DC input voltage range	150 - 450 V
Cooling	Convection
