Fronius IG Plus A 3.0-1 UNI User Manual

28
Installing a wall
bracket on an in-
dividual column
outdoors
When an inverter is installed outdoors on an individual column or on an upright metal car-
rier, the included weather shield must be installed along with the wall bracket.
1
Only applies to the two-part weather shield:
when positioning the two-part weather
shield and wall bracket, make sure that the-
re is no cross beam or wall behind the joint
of the two weather shield parts.
1
1
"click"
"click"
1
NOTE! When hanging the wall bracket on to the weather shield bolts, make sure
that:
- the wall bracket hangs upright
- the wall bracket hangs evenly from both bolts
1
1
1
2
0

Fronius IG Plus A 3.0-1 UNI Specifications

General

AC nominal output	3000 W
Max. apparent AC power	3000 VA
Max. output current	13 A
AC grid frequency	50 / 60 Hz
THD	<3%
Max. DC voltage	500 V
Number of MPP trackers	1
AC voltage range	183 V - 264 V
DC input voltage range	150 - 450 V
Cooling	Convection
