Fronius IG Plus A 3.0-1 UNI User Manual

94
Display Values in "Now" Display Mode
Selecting the
"Now" Display
Mode
Select the "Now" display mode
The first display value in the "Now" display
mode appears
Use the "Down" (2) key to scroll to the
next display value
Scroll back using the "Up" key (1)
Display values in
the ‘Now’ display
mode
(1) (2)
1
2
Output power
power supplied to grid at the particular
moment (Watts)
AC grid voltage
(Volts)
Output current
current supplied to the grid at the particu-
lar moment (Amperes)
*) only for multi-phase inverters
Grid frequency
(Hertz)
Solar module voltage
voltage of the solar array at the particular
moment (Volts)
*)
*)

Fronius IG Plus A 3.0-1 UNI Specifications

General

AC nominal output	3000 W
Max. apparent AC power	3000 VA
Max. output current	13 A
AC grid frequency	50 / 60 Hz
THD	<3%
Max. DC voltage	500 V
Number of MPP trackers	1
AC voltage range	183 V - 264 V
DC input voltage range	150 - 450 V
Cooling	Convection
