Fronius IG Plus A 3.0-1 UNI User Manual

146
Closing the in-
verter
1 2
3
The inverter changes into the startup phase and starts feeding power into the grid again
afterwards.
The operation status LED lits up green.
IMPORTANT! Make sure that the plastic dividers are underneath any data communication
wires that are present. .
1
1
3
2
4
1
3 Nm
2.21 ft. lb.
2
off
on
1
ON
AC
2
ON
OFF
3

Fronius IG Plus A 3.0-1 UNI Specifications

General

AC nominal output	3000 W
Max. apparent AC power	3000 VA
Max. output current	13 A
AC grid frequency	50 / 60 Hz
THD	<3%
Max. DC voltage	500 V
Number of MPP trackers	1
AC voltage range	183 V - 264 V
DC input voltage range	150 - 450 V
Cooling	Convection
