Fronius IG Plus A 3.0-1 UNI User Manual

83
EN-US
‘MODE’ is shown.
Press the ‘Enter’ key
The set protocol type is displayed.
Use the ‘Up’ and ‘Down’ keys to select
the ‘IFP’ protocol type (interface proto-
col):
Press the ‘Enter’ key to apply the ‘IFP’
protocol type.
The ‘IFP’ protocol type is applied, ‘MODE’
is displayed.
For setting the inverter baud rate without
exiting the ‘Basic Service’ menu follow the
steps in the enclosed section ‘Setting the
Inverter baud rate’, starting from step 3.
Press the ‘Esc’ key 2 x to exit the ‘Basic
Service’ menu
Setting the invert-
er baud rate
The inverter is in the ‘Basic Service’ menu,
the first parameter is displayed:
‘MIX MODE’ for multiphase inverters
3
4
5
6

Fronius IG Plus A 3.0-1 UNI Specifications

General

AC nominal output	3000 W
Max. apparent AC power	3000 VA
Max. output current	13 A
AC grid frequency	50 / 60 Hz
THD	<3%
Max. DC voltage	500 V
Number of MPP trackers	1
AC voltage range	183 V - 264 V
DC input voltage range	150 - 450 V
Cooling	Convection
