82
... the access code flashes.
Press the ‘Enter’ key
The inverter is now in the ‘Basic Service’
menu, the first parameter is displayed:
‘MIX MODE’ for multiphase inverters
‘DC MODE’ for single-phase inverters
Selecting the in-
terface protocol
for communica-
tion with other
data communica-
tion components
The inverter is in the ‘Basic Service’ menu,
the first parameter is displayed:
‘MIX MODE’ for multiphase inverters
‘DC MODE’ for single-phase inverters
Use the ‘Up’ and ‘Down’ keys to select
the ‘COMM’ parameter
Press the ‘Enter’ key
14
1
2

Fronius IG Plus A 3.0-1 UNI Specifications

General

AC nominal output	3000 W
Max. apparent AC power	3000 VA
Max. output current	13 A
AC grid frequency	50 / 60 Hz
THD	<3%
Max. DC voltage	500 V
Number of MPP trackers	1
AC voltage range	183 V - 264 V
DC input voltage range	150 - 450 V
Cooling	Convection
