Fronius IG Plus A 3.0-1 UNI User Manual

84
‘DC MODE’ for single-phase inverters
Use the ‘Up’ and ‘Down’ keys to select
the ‘COMM’ parameter
Press the ‘Enter’ key
‘MODE’ is shown.
Use the ‘Up’ and ‘Down’ keys to select
the ‘IFP’ parameter
Press the ‘Enter’ key
‘BAUD’ is displayed
Press the ‘Enter’ key
The set baud rate is displayed.
Use the ‘Up’ and ‘Down’ keys to select
the desired baud rate:
2400 / 4800 / 9600 / 14400 / 19200
Press the ‘Enter’ key
1
2
3
4
5
6
7

Fronius IG Plus A 3.0-1 UNI Specifications

General

AC nominal output	3000 W
Max. apparent AC power	3000 VA
Max. output current	13 A
AC grid frequency	50 / 60 Hz
THD	<3%
Max. DC voltage	500 V
Number of MPP trackers	1
AC voltage range	183 V - 264 V
DC input voltage range	150 - 450 V
Cooling	Convection
