39
EN
(12) Gas-test button
For setting the required gas flow rate on the gas pressure regulator.
After pressing this button, gas flows for 30 seconds. Press the button again to stop
the gas flow prematurely.
(13) Wire threading button
To thread the wire electrode into the torch hosepack with no accompanying flow of
gas or current
(14) Left adjusting dial with turn/press function
- For setting the sheet thickness, welding current, wire speed, F1, penetration sta-
bilizer and arc length stabilizer parameters
- For displaying help texts
Turn the adjusting dial to:
select parameters, change values, display long help texts
Press the adjusting dial to:
confirm a menu selection, apply values, call up help texts for parameters
(15) Favourites button
Individual parameters or parent folders can be assigned to it
(16) Filler metal info button
For showing the currently set filler metal
(17) Filler metal selection button
For selecting the filler metal
