Fuji Xerox DocuPrint CM505 da Administrator's Guide

3 Maintenance
72
Maintenance
3
14 Slide the transfer belt unit into the machine
and stop when the visible line reaches the
machine.
15 Lower the handles.
16 Push the front of the transfer belt unit to
reinstall it in the machine until it stops.
17 Close the inner cover.
18 Rotate the two lock levers of the inner cover
while pressing the cover with the other hand
to secure the inner cover.
