Fuji Xerox DocuPrint CM505 da Administrator's Guide

Replacing Consumables
71
Maintenance
3
10 Unpack a new transfer belt unit and place
the unit on a level surface.
11 Remove the protective parts as shown in the
illustration.
12 Hold and lift up the top handles of the
transfer belt unit.
Important • Do not hold the sides of the transfer belt
unit. It may degrade print quality.
13 Align the arrows on the transfer belt unit with
the arrows on the machine.
